DINP is a C9 phthalate plasticizer, produced from INA (Isononyl Alcohol) and PA (Phthalic Anhydride). It appears as a clear, colorless, and almost odourless oily liquid with solubility in most organic solvents. Compared with DOP, DINP typically requires a slightly higher dosage to achieve similar plasticizing efficiency. However, it offers superior electrical insulation, durability, migration resistance, and low-temperature flexibility. The longer carbon chain structure improves stability and reduces volatility. At the same Phr level, DINP-plasticized products generally demonstrate improved tensile strength, elongation, durability, and low-temperature flexibility than DOP-plasticized products.
High Plasticizing Efficiency & Enhanced Stability
Low Volatility & Good Migration Resistance
Good Aging Resistance & Low-temperature Flexibility
|
Item of Analysis |
Unit |
Value |
|
Appearance |
|
Transparent oil liquid |
|
Color |
APHA No. ≤ |
25 |
|
Acid Value |
KOH-mg/g ≤ |
0.05 |
|
Water Content |
Wt% ≤ |
0.1 |
|
Specific Gravity |
20/20℃ |
0.975±0.0005 |
|
Ester Content |
Wt% ≥ |
99.6 |
In iron drums, 200kg net weight per drum, total 80 drums (16MT) per 20’ FCL, OR
In IBC tank, 1,000kg net weight per tank, total 20 tanks (20MT) per 20’ FCL, OR
In flexibag, around 21-23MT per 20’ FCL.
If stored in tanks, purge N2 to prevent moisture absorption.
If stored in drums, keep the container sealed when not in used.
